| ITEM | DESCRIPTION |
| KINGPIN | 50.8 MM (2”)/89MM (3.5”) as per IS 6763(Part I) – Boltable Type. |
MAIN CHASSIS | Formed I Beam - 12 / 8 / 12 – Ladder type construction, Made with high strength steel-BSK46 with inner cross members providing maximum torisonal stability. |
OUTER MEMBER | The Skeleton is constructed with cross members Box Structure – 5mm Thk & duly strengthened and reinforced to the main chassis. |
| SUSPENSION | Tandem Heavy Duty multi leaf free ended laminated leaf spring. |
| AXLES | Round / square beam heavy duty axles – 2Nos. |
BRAKES | Dual line air brakes with relay emergency, Air reservoir & suitable brake chambers. ABS will be optional extras. |
TYRES | Tyres: – Nylon 10.00 x 20 / 11.00 x 20 - 08 No’s. Disc: – 7.50 x20 /8.00 x 20 – 08 No’s. Optional: - Radial Tyres - 10.00R20 / 11.00R20 - 08 No’s. Tubeless Tyres & Discs, Aluminum Disc. |
LANDING LEGS | Two speed landing legs at the front of the trailer – 1 Set. |
ELECTRICAL | 24V, 7Core socket, Lights as per AIS-113 standard. |
| GRIT BLASTING & PAINTING | Grit Blasting as per SA 2.5 standard, to clean rust & mill scale. Two coats of metal primer with 40 microns (DFT) & Final two coats of Enamel paint with 40 microns (DFT). |
| CONTAINER LOCKS | Container Twist locks – 4 No’s for 20 Ft - One Container. |
STANDARD ACCESSORIES | Twist lock for ISO Container, ABS Mudguard, Spare wheel carrier, Tool box etc. SUPD & RUPD as per AIS 113 standard. |
 |
| liba group tipper trucks，flatbed semi trailers trucks， |
 |
| liba group tipper trucks，flatbed semi trailers trucks |
BRAND NAMES OF LIBA GROUP BOUGHT OUT ITEMS
| SL.NO | PARTICULARS | BRAND/MANUFACTURER |
| 1 | CHASSIS STEEL | JSW, TATA, ESSAR, BSK 46 / EQVT. |
| 2 | M.S.SHEETS | JSW, TATA, ESSAR / EQVT. |
| 3 | FRAME WORK STEEL | SAIL / EQVT, IS 2062. |
| 4 | KING PIN | JOST, YORK, FUWA. |
| 5 | AXLE | FUWA, YORK, BPW. |
| 6 | SUSPENSION ASSEMBLY & LEAF SPRINGS | FUWA, YORK, BPW. |
| 7 | BRAKE ACCESSORIES / PNEUMATIC | WABCO, HALDEX, KNORR BREMSE. |
| 8 | PNEUMATIC HOSES & ADAPTORS | WABCO, GATES, POLYHOSE. |
| 9 | PAINTS | ASIAN, NEROLAC, BERGER, AKZONOBEL/EQVT. |
| 10 | WHEEL RIMS | WHEELS INDIA, YORK, FUWA, EQVT. |
| 11 | FASTENERS | TVS, UNBRAKO, LPS. |
| 12 | TYRES | CHAOYANG, |
